Example:
A:>syscfg --vflash=enable
vflash=enable
Applicable Systems All PowerEdge 11G systems or systems with iDRAC6
identify
Table 280. identify
Valid Arguments 0–254
Description
Flashes the identication LED for a specied number of seconds.
NOTE: Use 0 to stop the blinking of the LED.
Example:
A:>syscfg --identify=10
identify=10
Applicable Systems All PowerEdge 11G systems with a BMC
idracversion
Table 281. idracversion
Option Sub-option Valid Arguments Description
--idracversion
Displays the version information for the iDRAC
and the iDRAC rmware. This option cannot be
replicated.
--devid
NA
Reports the iDRAC device ID.
--devrevision
NA
Reports the iDRAC device revision.
--majorfwversion
NA
Reports the major rmware revision of iDRAC.
--minorfwversion
NA
Reports the minor rmware revision of iDRAC.
A:>syscfg --idracversion
devid=32
devrevision=0
majorfwversion=0
minorfwversion=40
kvmstatusonlcd
Table 282. kvmstatusonlcd
Option Sub-option Valid
Arguments
Description Applicable Systems
--
kvmstatusonlcd
NA
active,
inactive
Congures the Dell Virtual KVM (vKVM)
session status on the LCD.
PowerEdge 11G
systems
