berchannel
Table 254. berchannel
Valid Arguments enable, disable
Description
Enables or disables embedded ber channel. This option can be replicated.
Example:
A:>syscfg --fiberchannel=enable
fiberchannel=enable
Applicable Systems All PowerEdge systems prior to PowerEdge 12G systems.
oppy
Table 255. oppy
Option
--floppy
Valid Arguments auto, o, readonly
Description
Sets the diskette drive controller to auto, o, or readonly. This option is available on all
supported systems that have a supported diskette drive. This option can be replicated
Example:
A:>syscfg --floppy=auto
floppy=auto
Applicable Systems All PowerEdge systems prior to PowerEdge 12G systems.
formfactor
Table 256. formfactor
Valid Arguments read-only
Description
Displays the geometry of PowerEdge Blade systems. The option can have the following
values: halfheight (the Blade systems occupies 1 slot of the chassis), halfheight,
dualwide (the Blade system occupies 2 horizontal slots of the chassis), fullheight (the
Blade system occupies 2 vertical slots of the chassis), fullheight, dualwide (the Blade
system occupies 4 slots of the chassis) and quarterheight (the Blade systems occupies
half slot of the chassis).
Example:
A:>syscfg --formfactor=fullheight, dualwide
formfactor=fullheight, dualwide
Applicable Systems
All PowerEdge blade systems prior to PowerEdge 12G systems.
