Example:
A:>syscfg --embscsiraidchb=raid
embscsiraidchb=raid
Applicable Systems All PowerEdge systems prior to PowerEdge 12G systems
embsdcardredundancy
Table 240. embsdcardredundancy
Valid Arguments mirrormode, disable
Description
Sets the redundancy to mirrormode or disabled.
If set to mirrormode, read-write operation occurs on both the secure digital (SD) cards.
If one of the SD cards fails and is replaced, on booting, the data is copied to that SD
card.
If set to disable, read-write operation occurs only on SD card 1.
On Blade systems, disable the vash key to congure this option.
Example:
A:>syscfg --embsdcardredundancy=mirrormode
embsdcardredundancy=mirrormode
Applicable Systems This option is degraded.
redmem
Table 241. redmem
Valid Arguments o, spare, mirror, DDDC
Description
Allows selection of the required redundant memory mode, or disables redundant
memory. This option can be replicated.
Example:
A:>syscfg --redmem=off
redmem=off
Applicable Systems PowerEdge systems with Intel Xeon 7500 series processor
power
Table 242. power
Valid Arguments NA
Description
For details about the power suboptions and arguments, see Sub Options For Power
Option.
Applicable Systems PowerEdge 11G systems
tcm
Table 243. tcm
Option
tcm
Valid Arguments NA
