Group SYSCFG Commands Equivalent RACADM Commands
--ErrPrompt BIOS.MiscSettings.ErrPrompt
--NumLock BIOS.MiscSettings.NumLock
--ForceInt10 BIOS.MiscSettings.ForceInt10
Processor Settings --DcuIpPrefetcher BIOS.ProcSettings.DcuIpPrefetcher
--DcuStreamerPrefetcher BIOS.ProcSettings.DcuStreamerPrefetcher
--LogicalProc BIOS.ProcSettings.LogicalProc
--ProcExecuteDisable BIOS.ProcSettings.ProcExecuteDisable
--ProcHwPrefetcher BIOS.ProcSettings.ProcHwPrefetcher
--ProcVirtualization BIOS.ProcSettings.ProcVirtualization
--RtidSetting BIOS.ProcSettings.RtidSetting
--ProcX2Apic BIOS.ProcSettings.ProcX2Apic
SATA Settings --WriteCache BIOS.SataSettings.WriteCache
--SecurityFreezeLock BIOS.SataSettings.SecurityFreezeLock
Serial Communication --ConTerrmType BIOS.SerialCommSettings.ConTermType
--ExtSerialConnector BIOS.SerialCommSettings.ExtSerialConnector
--FailSafeBaud BIOS.SerialCommSettings.FailSafeBaud
--RedirAfterBoot BIOS.SerialCommSettings.RedirAfterBoot
Slot Disablement --Slotn BIOS.SlotDisablement.Slotn
System Information --svctag BIOS.SysInformation.SystemServiceTag
System Security --AcPwrRcvryDelay BIOS.SysSecurity.AcPwrRcvryDelay
--PwrButton BIOS.SysSecurity.PwrButton
--SetupPassword BIOS.SysSecurity.SetupPassword
--SysPassword BIOS.SysSecurity.SysPassword
System Power --maxpowercap System.Power.Cap.MaxThreshold
--minpowercap System.Power.Cap.MinThreshold
--capenable System.Power.Cap.Enable
SYSCFG Options On PowerEdge Systems Prior To PowerEdge 12G Systems
The following are the valid options and arguments supported on PowerEdge systems earlier than PowerEdge 12G systems.
assignintr
Table 224. assignintr
Valid Arguments standard, distributed
Description Controls the interrupt assignment of PCI devices in the system. This option is set to
standard by default, causing standard interrupt routing that uses interrupt A, B, C, and
D for all PCIe devices. When set to distributed, the interrupt routing is swizzled at the
MCH root ports to minimize sharing of interrupts across all PCIe (and PCI-X in the
Programmable Interrupt Controller (PIC) mode) devices.
