DTKTORACADM
The DTK SYSCFG deployment scripts are converted to equivalent RACADM scripts, that helps in migration to utilize RACADM in the
deployment solution. The utility has the conversion tool for converting the SYSCFG scripts in both environments: Microsoft
Windows and Linux operating systems. Starting 12th generation of PowerEdge servers and later, selected set of SYSCFG commands
are a part of the DTK sample scripts. The list of DTK sample scripts are present in \Toolkit\Tools\CONVERTER\windows_scripts.lst
for Microsoft Windows operating systems and toolkit/Converter/ linux_scripts.lst for Linux operating system. The converted scripts
are available in the folder racscripts.
Table 221. DTKTORACADM Command on Windows Operating System
Valid Arguments dtktoracadm.exe or dtktoracadm.exe windows_scripts.lst debug
Description On systems running Windows operating system, run the command, where windows_scripts.lst is
the input ๎le which contains the list of path to run the RACADM scripts and debug is an option
which list the ๎le status.
Applicable Systems
All PowerEdge 12 and later systems.
Table 222. DTKTORACADM Command on Linux Operating System
Valid Arguments python dtktoracadm.py or python dtktoracadm.py linux_scripts.lst
debug
Description On the system running Linux operating system, in the prompt type the command, where
linux_scripts.lst is the input which contains the list of path to run the RACADM scripts and
debug is an option which list the ๎le status.
Applicable Systems
All PowerEdge 12 and later systems.
The set of converted commands are available in dtktoracadm_dict.map. For more information see, Dell OpenManage Deployment
Toolkit User's Guide or Dell OpenManage Deployment Toolkit Installation Guide. The following table lists the set of commands
available:
Table 223. SYSCFG equivalent RACADM commands
Group SYSCFG Commands Equivalent RACADM Commands
iDRAC Settings
lcp --dnsdhcp iDRAC.IPv4.DNSFromDHCP
lcp --domainname iDRAC.NIC.DNSDomainName
lcp --dnsracname iDRAC.NIC.DNSRacName
lcp --dnsregisterrac iDRAC.NIC.DNSRegister
--idractype iDRAC.Info.Type -z legacy
--autoneg iDRAC.NIC.Autoneg
--gateway iDRAC.IPv4.Gateway
--ipaddress iDRAC.IPv4.Address
--macaddress iDRAC.NIC.MACAddres
--nicselectionfailover iDRAC.NIC.Failover
--subnetmask iDRAC.IPv4.Netmask
--vlanid iDRAC.NIC.VLanID
--dnsserver1v6 get iDRAC.IPv6.DNS1
--dnsserver2v6 get iDRAC.IPv6.DNS2
