Configure the four point-to-point interfaces connected to leaf switches. Assign IP addresses per Table 1.
Configure a loopback interface to be used as the router ID. Enable OSPF on the interfaces with process 1
area 0.
Note: If multiple loopback interfaces exist on a system, the interface with the highest numbered IP address
is used as the router ID. This configuration only uses one loopback interface.
Z9100-Spine1
Z9100-Spine2
interface ethernet 1/1/1
description "S4148F-Leaf1 eth 1/1/29"
no switchport
ip address 192.168.1.0/31
ip ospf 1 area 0
no shutdown
interface ethernet 1/1/2
description "S4148F-Leaf2 1/1/29"
no switchport
ip address 192.168.1.2/31
ip ospf 1 area 0
no shutdown
interface ethernet 1/1/3
description "S4248FB-Leaf3 eth 1/1/47"
no switchport
ip address 192.168.1.4/31
ip ospf 1 area 0
no shutdown
interface ethernet 1/1/4
description "S4248FB-Leaf4 eth 1/1/47"
no switchport
ip address 192.168.1.6/31
ip ospf 1 area 0
no shutdown
interface loopback 0
description "Router ID"
ip address 10.0.1.1/32
no shutdown
interface ethernet 1/1/1
description "S4148F-Leaf1 eth 1/1/30"
no switchport
ip address 192.168.2.0/31
ip ospf 1 area 0
no shutdown
interface ethernet 1/1/2
description "S4148F-Leaf2 eth 1/1/30"
no switchport
ip address 192.168.2.2/31
ip ospf 1 area 0
no shutdown
interface ethernet 1/1/3
description "S4248FB-Leaf3 eth 1/1/48"
no switchport
ip address 192.168.2.4/31
ip ospf 1 area 0
no shutdown
interface ethernet 1/1/4
description "S4248FB-Leaf4 eth 1/1/48"
no switchport
ip address 192.168.2.6/31
ip ospf 1 area 0
no shutdown
interface loopback 0
description "Router ID"
ip address 10.0.1.2/32
no shutdown
