Specifications | 89

PRINTER SPECIFICATIONS SCANNER SPECIFICATIONS

COPIER SPECIFICATIONS

ITEM DESCRIPTION

Printing method Color laser beam printing

Printing speed

a.It will be affected by operating system used, computing performance,

application software, connecting method, media type, media size and

job complexity.

Up to 20 ppm (A4), 21 ppm (Letter)

Duplex printing

speed

Up to 7 ipm (A4/Letter)

First print out

time

Black &

White

From ready: Less than 25 seconds

From coldboot: Less than 75 seconds

Color

From ready: Less than 25 seconds

From coldboot: Less than 75 seconds

Print resolution Max. 2,400 x 600 dpi effective output

Printer language SPL, PostScript 3, PCL5ce and PCL6

OS compatibility

b.Visit www.dell.com to download the latest software version.

• Windows: 2000/XP/2003/2008/Vista

• Linux: RedHat 8.0~9.0, Mandrake 9.2~10.1,

SuSE 8.2~9.2, Fedra Core 1~4

• Macintosh: Mac OS X 10.3~10.5, Universal Mac

Interface • High speed USB 2.0

• Ethernet 10/100 Base TX (embedded type)

ITEM DESCRIPTION

Compatibility TWAIN standard/WIA standard

Scanning method

Color CCD

Resolution

a.Due to the applications for scanning, the maximum resolution might

differ.

TWAIN

standard/

WIA standard

• Optical: Up to 600 x 1,200 dpi

• Enhanced: Up to 4,800 x 4,800

dpi

Scan to USB 100, 200, 300 dpi

Scan to E-

mail

100, 200, 300 dpi

Scan to PC 75, 150, 200, 300, 600 dpi

Network Scan

File format

PDF, TIFF, JPEG

, BMP

b.JPEG is not available when you select the mono mode in scan color.

Effective

scanning length

• Scanner glass: 289 mm (11.38 inches)

• DADF: 348 mm (13.7 inches)

Effective

scanning width

Max. 208 mm (8.2 inches)

Color bit depth • Internal: 36 bit

• External: 24 bit

Mono bit depth • 1 bit for black & white mode

• 8 bit for gray scale

ITEM DESCRIPTION

Copy Speed

a.Copy speed is based on Single Document Multiple Copy.

Up to 20 cpm (A4), 21 cpm (Letter)

Copy

resolution

Text • DADF: Up to 600 x 600 dpi

• Scanner glass: Up to 600 x 600 dpi

Text/photo Up to 600 x 600 dpi

Magazine Up to 600 x 600 dpi

Photo • DADF: Up to 600 x 600 dpi

• Scanner glass: Up to 1,200 x 1,200

dpi

Zoom range • DADF: 25% to 100%

• Scanner glass: 25% to 400%
