Using Your Printer in Linux

Using the Unified Driver

Configurator

Unified Linux Driver Configurator is a tool primarily intended for

configuring Printer or MFP devices. Since an MFP device

combines the printer and scanner, the Unified Linux Driver

Configurator provides options logically grouped for printer and

scanner functions. There is also a special MFP port option

responsible for the regulation of access to an MFP printer and

scanner via a single I/O channel.

After installing the Unified Linux driver, the Unified Linux Driver

Configurator icon will automatically be created on your desktop.

Opening the Unified Driver

Configurator

Double-click

Unified Driver Configurator

on the

desktop.

You can also click the Startup Menu icon and select

Dell

Unified Driver

and then

Unified Driver Configurator

Press each button on the Modules pane to switch to the

corresponding configuration window.

Printers Configuration button

Scanners Configuration button

Ports Configuration button

You can use the onscreen help by clicking

Help

After changing the configurations, click

Exit

to close the

Unified Driver Configurator.

Printers Configuration button

Ports Configuration button
