New feature Description
Support for Dell’s 13th generation of PowerEdge servers With this version, you can configure the 13th generations of Dell
PowerEdge servers through Integrated Dell Remote Access
Controller (iDRAC) with Lifecycle Controller (LC)
Existing features and functionalities
Table 2. Features and functionalities
Feature Functionality
Configuration Manager distributed environment Support for Configuration Manager, when the configuration
manager is set up in a distributed environment.
Configure and deploy operating system on Dell’s 11th generation
and 12th generation of PowerEdge servers.
You can configure Dell’s 11th generation or 12th generation of
PowerEdge servers using DLCI through Lifecycle Controller. All
the features of previous version of DLCI are supported for 12th
generation or 11th generation PowerEdge servers.
A single installer to install and configure DLCI
You can use the single installer to install DLCI 3.3 in
environments (Configuration Manager 2012 SP2, Configuration
Manager 2012 R2 SP1, Configuration 2012 R2, Configuration
Manager 2012 SP1, or Configuration Manager 2012) based on
the version of Configuration Manager present in the system. If a
DLCI 3.2 is present, then the installer initiates an upgrade. The
installer deploys appropriate components based on the
Configuration Manager version.
Automatically configure Dell Provisioning Server You can automatically configure Dell Provisioning Server for
non-administrator users by selecting the Automatically
configure Dell Provisioning Server user permissions option
during installation.
Deploying customized images using Dell driver CAB files You can create and deploy customized images on Dell Enterprise
servers. For more information, see Adding Dell driver packages.
Platform Restore You can restore a profile for a system or a collection that
includes:
• Scheduling a backup, and exporting system profiles to an
external share/vFlash.
• Importing the saved system profiles from an external share/
vFlash.
• Configuring Part Replacement properties for a system or a
collection.
For more information, see Platform restore for a system and
Platform restore for a collection.
Viewing and exporting the Lifecycle Controller logs You can view the Lifecycle Controller logs of a system or a
collection in a readable format and save or export the logs to
a .CSV file. In addition, you can filter logs and view the number
of logs based on the search string. For more information, see
Viewing Lifecycle Controller logs and Viewing and exporting
Lifecycle Controller logs for a collection.
Configure network interface cards (NICs) and converged
network adapters (CNAs)
You can configure different attributes of specific NICs or CNAs
in the system and save them to a profile.
The saved profiles can later be applied to a collection as part of
the hardware configuration or operating system deployment, or
both.
