NOTE: For the PowerEdge 11G systems, the Slot Length and Slot Type fields may show the status as Not Applicable
instead of Unknown.
Platform restore for a system
You can use this option on the System Viewer utility to perform the following functions:
• Export a system profile. For more information, see Exporting the system profile.
• Import a system profile. For more information, see Importing the system profile.
• Manage profiles.
• Configure Part Replacement properties for a system. For more information, see Configuring part replacement properties for a
system.
Prerequisites to export or import a system profile
You must upgrade the firmware to the following versions:
• iDRAC Firmware for blade systems to version 3.30 or higher.
• iDRAC Firmware for rack and tower systems to version 1.80 or higher.
• Lifecycle controller firmware to version 1.5 or higher.
• When exporting a system profile, if you want to schedule a backup, then you must have administrative privileges to access the
iDRAC vFlash Card or a Network share.
For more information on updating you firmware versions, see Comparing and Updating the Firmware Inventory.
Exporting the system profile
About this task
You can create a backup of the system profiles and export it to an iDRAC vFlash Card or a Network share. This feature backs up the
following:
• Hardware and firmware inventory such as BIOS, LOMs, and Storage Controllers (RAID level, virtual disk, and controller
attributes).
• System information such as service tag, system type, and so on.
• Lifecycle Controller firmware images, system configuration, and iDRAC system profiles.
To export the system profile:
Steps
1. On the System Viewer utility, select Platform Restore.
For the 11th generation of PowerEdge servers, the utility checks for a valid license of the Dell vFlash SD card on the Lifecycle
Controller of the system and for 12th and 13th generations of PowerEdge servers, the utility checks for an Enterprise license,
and also the firmware version. If a valid license is present, the Platform Restore screen is displayed.
NOTE: This feature is available only for Lifecycle Controller version 1.5 and later.
2. On the Platform Restore screen, select the Export Server Profile option and click Next. The options to select the vFlash
media or location are displayed.
3. Select one of the following options:
• vFlash media: backs up on the iDRAC vFlash Card.
NOTE: In a vFlash card, an existing system profile is overwritten when you export a system profile.
• Network share: backs up on a shared location on the network. If you choose this option you must specify the following
information:
– Existing share: Specify share location if you are creating a backup for the first time. This information is cached for
subsequent backups and you can select the existing location from the drop-down box.
66
