8. Click Save as profile to save the modified NIC profile.
Configuring adapters
About this task
To configure the adapters:
Steps
1. Select the adapter on the Network Adapter Configuration screen and click Configure.
The Adapter Configuration dialog box is displayed.
2. Select one of the following options:
• Configure adapter settings — to configure the settings.
• Copy settings from adapter — to copy the configuration settings from an adapter that is already configured.
3. Click Configure.
The Configure Adapter dialog box is displayed.
4. Select the port that you want to configure and click Configure.
5. Select one of the following options:
• Configure port settings — to configure the port settings. Proceed to the next step if you want to configure the port
settings manually.
• Copy settings from port — to copy the port settings from a port that is already configured. Proceed to step 7 if you are
copying the port settings.
6. You need to choose the personalities for each partition on the port, enter bandwidth and configure settings for each
personality. One port can have up to four partitions with one personality assigned to each partition.
Under Personalities and Settings, select the personality against each partition and set the minimum and maximum bandwidth.
You can select from one of the following options:
• NIC
• iSCSI
• FCoE
NOTE: You can select the personalities only for CNAs and not for NICs.
7. Click Port Settings to configure the NIC and iSCSI parameters. For more information, see Configuring NIC and iSCSI
Parameters.
8. Click OK to save the configurations.
Configuring NIC and iSCSI parameters
About this task
You can configure the NIC and iSCSI parameters from the Port Settings screen.
To configure the NIC and iSCSI parameters:
Steps
1. In the Port Settings screen, on the NIC tab, specify the following parameters:
• Select All — select to check all the options available for NIC.
• Boot protocol — select the protocol for booting the system. You can choose from PXE, iSCSI, or FCoE.
• Wake on LAN — select to switch on the system throughout your LAN. You can choose to enable or disable this option.
• Wake on LAN link speed — specify the Wake on LAN link speed from the drop-down list.
• VLAN mode — select to add your system to a VLAN if it is not located on the same network switch. You can choose to
enable or disable this option.
• Link speed — select the NIC link speed.
• Flow Control — select the data flow control.
• IP auto configuration — select to automatically configure the IP address for the system. You can choose to enable or
disable this option.
