Steps
1. In the BIOS Configuration screen, select Create a New Profile or Edit an Existing Profile, and click Browse to browse for the
profile.
2. Click the Boot or UEFI Sequence tab.
The current BIOS or UEFI boot sequence and hard disk drive sequence is displayed.
3. Use the Move Up and Move Down to change the BIOS or UEFI boot sequence or the hard disk drive sequence.
After you manually map SAN boot device in server, it is visible as hard disk drive sequence. To change the boot sequence for
SAN boot device, use Move Up to move up the SAN boot device in the hard disk drive sequence until it is the first boot device
in the hard disk drive sequence.
NOTE: If more than one SAN boot device is present in the hard disk drive sequence and you select a specified
device as the first boot device, the selection of the first boot device is based on the sequence in the Lifecycle
Controller.
4. Click OK to save the changes.
NOTE:
• For 13th generation of Dell PowerEdge servers, you can view the BIOS attributes and boot sequence of the currently
saved boot mode only.
• Click Reset to reset any changes made.
• The following task sequence works: Boot Mode with Boot Sequence followed by any of these configuration tasks,
NIC, or RAID; Optionally included with iDRAC configuration tasks.
• The following task sequence does not work: Boot Mode with Boot Sequence followed by only an iDRAC and only an
OSD configuration task does not work.
• The following task sequence partially works: If boot mode and boot sequence are applied together, then only boot
mode works.
Viewing and configuring RAID
About this task
This feature enables you to view and configure RAID on the server. To configure RAID:
Steps
1. On the System Viewer utility, click RAID Configuration.
The RAID Configuration screen displays the RAID information of your system, such as number of virtual disks, their controller
IDs, RAID levels, and physical disks.
2. Click Create RAID profile to create a new RAID configuration profile using Array Builder. For more information on using the
Array Builder, see
Using the Array Builder.
Configuring iDRAC profiles for a system
This features enables you to define the iDRAC configuration and save it and apply the profile to a collection as part of the workflow
while deploying an operating system.
You can create or edit iDRAC profiles for a system using the System Viewer utility.
Creating an integrated Dell Remote Access Controller profile
About this task
To create an iDRAC profile:
Steps
1. On the System Viewer utility, click iDRAC Configuration.
The iDRAC Configuration options are displayed.
2. Select Create a New Profile and click Next.
3. Click the Network Configuration tab.
