S.No Target Server Profile Settings What is Applicable
6. Rack, Tower, or Blade systems Common IP Configuration
attributes only.
Common IP Configuration
attributes.
7. Rack, Tower, or Blade systems
without iDRAC6 enterprise
card
LAN Settings with NIC mode
set to Dedicated.
Nothing is applied as this
attribute needs the iDRAC6
enterprise card.
8. Rack, Tower, or Blade systems LAN Settings with NIC mode
set to Shared.
Attribute is applied only to
Rack and Tower systems and
only if the host operating
system is configured for NIC
teaming.
9. Rack, Tower, or Blade systems IPv4 Configuration where IP
range specified is less than the
number of systems.
Nothing is applied and an error
is displayed in the OS
deployment workflow.
10. Rack, Tower, or Blade systems
booted to Unified Server
Configurator
All four types of attributes are
configured.
All attributes applicable to the
systems.
3. Click Next to select an advertisement.
NOTE: If there is an error while applying an iDRAC profile, the operating system deployment process stops.
Exporting the system profiles before and after hardware configuration
You can use this option to create a backup of the system profiles and export it to an iDRAC vFlash Card or a Network share.
About this task
To export the system profiles, perform the following:
Steps
1. Select Configure when to Export Hardware Configuration.
NOTE: All the controls and options are enabled in this page if this option is selected.
2. Select the options Before and/or After to export the system profiles before and/or after hardware configuration.
NOTE: You can either select both the Before and After option or any one of the options. If you do not select any
option, the Do not Export option is considered and a warning is displayed before proceeding.
3. Enter an Export File Passphrase. See step 4 in Exporting the system profile to include an Export file passphrase that should be
in a specific format.
4. Enter an Export File Name Prefix.
NOTE: You can specify a file name prefix that is the same as an earlier Export file and in such situations, the Export
file is overwritten.
The Export files are appended with the hostname of the system and saved before hardware configuration in the following
format: <Before>_<prefix>-<node_id>
The Export files after hardware configuration are saved in the following format: <After>_<prefix>-<node_id>
5. Select Continue on error to continue the deployment, even if there is an error.
6. Select vFlash media or Network share. See step 3 in Exporting the system profile for more information about share selection.
7. Click Next to export the system profiles.
Next steps
To restore the backup files or system profiles, use the Platform restore for a system option on the System Viewer to import a
system profile or Platform restore for a collection option on the Configuration Utility to import the system profiles in a collection.
