Table 4. Broadcom profile settings
S.No Target Server Setting Profile Settings What is Applied
1. Dual Port NIC (partition
disabled)
Dual Port NIC
Dual Port Quad Partition NIC
Dual Port Quad Partition NIC
Partition is enabled when the
system reboots.
2. Dual Port NIC (partition
disabled)
Dual Port NIC Dual Port NIC
Port level settings are applied
when the system reboots.
3. Dual Port NIC (partition
disabled)
Dual Port Quad Partition NIC Dual Port Quad Partition NIC
Partition is enabled when the
system reboots.
4. Dual Port Quad Partition NIC Dual Port NIC
Dual Port Quad Partition NIC
Dual Port Quad Partition
5. Dual Port Quad Partition NIC Dual Port NIC Nothing is applied as there is
no match between the target
server setting and profile
setting.
6. Dual Port Quad Partition NIC Dual Port Quad Partition NIC Dual Port Quad Partition
4. Click Next to apply an iDRAC profile.
NOTE: If there is an error while applying a NIC/CNA profile, the operating system deployment process continues to
the next step. While applying an attribute using Config Utility, it does not check the dependent attributes value.
After the hardware configuration task is complete, use Network Adapter Comparison Report in Config Utility to
check if the attributes have been applied successfully.
Applying FC HBA profiles and FC SAN boot attributes on a collection
You can apply FC HBA profiles and FC SAN boot attributes from Configuration utility. You can create a FC HBA profile in the
System Viewer utility, and provide the FC SAN boot attributes as a CSV file while applying the settings in Configuration utility.
Applying a FC HBA profile on a collection
About this task
To apply a FC HBA profile on a collection, perform the following steps:
Steps
1. Click Browse and select the FC adapter port profile that you created by using the System Viewer utility. This profile is applied
during the hardware configuration process. For more information on creating FC HBA profiles, see Creating an FC HBA profile.
2. After you select FC adapter port profile, you can validate if the configuration is applied based on the following rules mentioned
in Table 5:
