In this case, the Next button is disabled and you can directly click Reboot targeted collection. The hardware configuration
tasks are submitted based on the selections you made in the previous steps and you can view the status of tasks on Task
Viewer.
NOTE: If you select a server to boot from a SAN device, you should skip deploying the operating system on a
collection from the Configuration Utility.
17. If you want to deploy the operating system:
• To deploy Windows operating systems: Select Windows Operating System, then select the advertisement to advertise the
task sequence to the collection, and the operating system for deployment on the collection.
• To deploy non-Windows operating systems: Select Non-Windows Operating System, select the operating system, provide
details, and then click Next.
• Other option to the Boot, Credentials, and Browse button are disabled for Non-windows deployment in Select ISO Image.
18. Under Select Lifecycle Controller bootable media, select one of the following options:
• Boot to Network ISO — Reboots specified ISO.
• Stage ISO to vFlash and Reboot — Downloads the ISO to vFlash and reboots.
• Reboot to vFlash (ISO Must be present on vFlash) — Reboots to vFlash. Ensure that the ISO is present in the vFlash.
NOTE: To use the Reboot to vFlash (ISO Must be present on vFlash) option, the label name of the partition
created on vFlash must be ISOIMG.
• Select the Use Network ISO as Fallback check box if you want the network ISO to be a fallback step.
• Click Browse and select the path where the Dell Lifecycle Controller bootable media is saved.
NOTE: If you have set a default share location for the Lifecycle Controller boot media, the default location
populates automatically. For more information, see Setting a default share location for the Lifecycle Controller boot
media.
19. Type the user name and password for accessing the share where the Dell Lifecycle Controller bootable media is located.
20. Click Reboot Targeted Collection. This selection sends the jobs for each system in the collection to the Task Viewer. To view
the current tasks in the queue and their status, open the Task Viewer by clicking the Dell icon on the task bar. For more
information on Task Viewer, see
Task Viewer.
After a system with iDRAC receives the WS-MAN command, it reboots to Windows PE and runs the advertised task
sequence. It then automatically boots to the Lifecycle Controller boot media, depending on the boot order you created in the
task sequence.
NOTE: If you want to update a system after you deploy the operating system, and the system services are still
unavailable, then you can reset the iDRAC using the iDRAC web-based interface. For more information, see the
Dell
Lifecycle Controller Remote Services User’s Guide
available at Dell.com/support/home.
NOTE: If a yellow bang appears under device manager after you deploy Windows 2016 operating system, then
download and install appropriate drivers from Dell.com/support/home.
After the deployment is successful, the system with iDRAC moves to the Managed Dell Lifecycle Controller (OS Deployed)
collection under All Dell Lifecycle Controller Servers.
NOTE: If you change the host name of the target systems after you deploy the operating system, the system
continues to appear under the Managed Dell Lifecycle Controller (OS Deployed) collection on the Configuration
Manager console. You do not need to re-discover the system when you change the host name.
Updating firmware during OS deployment
About this task
To update the firmware:
Steps
1. Select one of the following options:
• Dell PDK catalog — to specify a Dell PDK catalog that you can use to compare the firmware inventory. To specify a PDK
catalog, do the following:
