C:\Program Files (x86)\Dell\DPS\ProvisionWS\bin\import.exe –CheckAuthorization true.
Changing the administrative credentials used by Dell Lifecycle Controller Integration for
Configuration Manager
Use the following commands to change the administrative credentials for Configuration Manager used by DLCI:
To set the user name:
C:\Program Files (x86)\Dell\DPS\ProvisionWS\bin\import.exe –CIuserID [New Console
Integration Admin User ID]
To set the password:
C:\Program Files (x86)\Dell\DPS\ProvisionWS\bin\import.exe -CIpassword [New Console
Integration Admin Password]
NOTE: The commands are case sensitive.
Using the Graphical User Interface
You can also use the Graphical User Interface (GUI) to change the security configurations.
Use the following command to open the GUI screen:
C:\Program Files (x86)\Dell\DPS\ProvisionWS\bin\import.exe -DisplayUI
NOTE: The DisplayUI term is case sensitive.
Using the Array Builder
The Array Builder allows you to define arrays and disk sets with all available RAID settings, logical drives or virtual disks of varying
sizes or use all available space, and assign hot spares to individual arrays or assign global hot spares to the controller.
When a controller is created, a default variable condition, array and disk(s) are created to ensure a valid configuration. You can
choose to leave the controller un-configured with disks set to non-RAID, or you can add arrays or perform other actions.
Defining rules with the Array Builder
You can define rules to match configurations based on the following:
• Detected slot number that the controller is in or just the embedded controller, if any.
• Number of disks that are attached to the controller.
• Apply a blanket configuration to any controller the Array Builder finds.
You can also apply configuration rules based on the RAID profiles detected on the server. This allows you to define different
configurations to different servers even if the detected hardware is identical.
Creating a RAID Profile using Array Builder
About this task
To create a RAID Profile:
You can also import an existing profile and modify the configurations using the Array Builder. For more information on importing a
profile, see Importing a profile.
Steps
1. Launch the System Viewer utility, click RAID Configuration → Create RAID Profile.
29
