Creating a custom task sequence
1. Launch the Configuration Manager Console.
The Configuration Manager Console screen is displayed.
2. In the left pane, select Software Library → Overview → Operating Systems → Task Sequences.
3. Right-click Task Sequences, and then click Create Task Sequence.
The Create Task Sequence Wizard is displayed.
4. Select Create a new custom task sequence, and click Next.
5. Enter a name for the task sequence in the Task sequence name text box.
6. Browse for the Dell boot image that you had created, and click Next.
The Confirm the Settings screen is displayed.
7. Review your settings and click Next.
8. Click Close in the confirmation message box that is displayed.
Editing a task sequence
1. Launch the Configuration Manager Console.
The Configuration Manager Console screen is displayed.
2. In the left pane, select Software Library → Operating Systems → Task Sequence.
3. Right-click the task sequence that you want to edit and click Edit.
The Task Sequence Editor window is displayed.
4. Click Add → Dell Deployment → Apply Drivers from Dell Lifecycle Controller.
The custom action for your Dell server deployment is loaded. You can now make changes to the task sequence.
NOTE: When editing a task sequence for the first time, the error message, Setup Windows and Configuration
Manager is displayed. To resolve the error, create and select the Configurations Manager Client Upgrade package.
For more information about creating packages, see the Configuration Manager documentation at
technet.microsoft.com.
Configuring the task sequence steps to apply operating system image
and driver package
The scope of this document includes information only on the DLCI feature to apply operating system image and add Dell drivers.
Applying the operating system image
About this task
NOTE: Before you begin this task, make sure that you have the required operating system image file (.wim file) within
the Operating System Images tree in the Configuration Manager.
To apply the operating system image:
Steps
1. In the left pane of the Task Sequence Editor, under Deploy Operating System, click Apply Operating System Image.
2. Select one of the following options:
• Apply operating system from a captured image
• Apply operating system from an original installation source
3. Browse and select the operating system location and click OK.
