Applying Drivers from the task sequence
Based on the operating system you want to deploy, either apply drivers from the Lifecycle Controller or the Configuration Manager
repository. Use the drivers in the Configuration Manager repository as backup.
Applying drivers from Lifecycle Controller
About this task
To apply drivers from the Lifecycle Controller:
NOTE: If you edit the task sequence to which drivers are exposed from the Lifecycle Controller option checked, the
errors in step 7 might not be reflected in the step status and in the Missing Objects dialog box. Configure the Apply
Drivers from Dell Lifecycle Controller option before you apply the changes.
Steps
1. Create a new task sequence if there is no existing task sequence, or edit the task sequence to which drivers are exposed from
the Lifecycle Controller.
2. Select Apply Operating System Images.
3. Under the Apply operating system from a captured image, select and verify the image package and image.
4. Clear the Use an unattended or sysprep answer file for a custom installation check box.
5. Select Apply Windows Settings.
6. Type the licensing model, product key, administrator password, and time zone.
7. Select Apply Drivers from Dell Lifecycle Controller and select an operating system from the drop-down list.
8. Type the user name and password with administrator credentials to access the Configuration Manager console.
9. Select Apply Driver Package. Click Browse and select a driver package from the list of driver packages available in
Configuration Manager.
10. Click OK to close the Task Sequence Editor.
11. Advertise the task sequence that you have edited.
12. Create a Lifecycle Controller Boot Media. For more information, see Creating a Lifecycle Controller boot media.
Importing DLCI Dell server driver packages
About this task
DLCI provides a wizard to create driver packages in Configuration Manager, based on the server-operating system combination
from the drivers available in the Dell Systems Management Tools and Documentation DVD. These packages are used in the task
sequences that are used for operating system deployment.
Steps
1. In the left pane, select Software Library → Overview→Operating Systems → Driver Packages.
2. Right-click Driver Packages, select DLCI Server Driver Package → Import Dell DLCI Server Driver Package. The Dell DLCI
Server Driver Package Import Wizard is displayed asking for the location of the Systems Management DVD.
NOTE: If you have downloaded an ISO image, then create a physical disk or mount it on a virtual drive.
3. Select the drive in which you inserted the DVD and click Next.
A list of driver packages for a combination of servers and operating systems is displayed.
4. Select the required packages and click Finish.
A progress bar displays the status of the import. After the import is complete, the import summary is displayed.
NOTE: The import of drivers may take more time and the progress bar may not be updated immediately.
5. Click Close.
