NOTE:
• Make sure that you import a DTK file package from the site server and not from the admin console.
• Support for DTK self-executable zip file.
2. Launch the Configuration Manager Console.
3. In the left pane, select Software Library → Overview → Application Management → Packages.
4. Right-click Packages and select DLCI Server Deployment → Import DLCI Dell Driver Cabs.
The DLCI WinPE Driver Configuration Wizard screen is displayed.
5. Click Browse and navigate to the file or self-extractable zip file that you downloaded.
The selected CAB file version, Windows PE version, and architecture are displayed in Cab Selection for Import section on
DLCI WinPE Driver Configuration Wizard.
NOTE: If the WinPE drivers are already installed on this system, then the following message is displayed:
WinPE drivers are already present on this system, importing Cab file will be overwriting the existing WinPE drivers.
Are you sure you want to continue?
6. Follow steps 7 to 11 in the Upgrading Dell driver CAB files section for creating a boot image.
Upgrading Dell driver CAB files
1. Launch Configuration Manager Console.
2. In the left pane, select Software Library → Overview → Application Management → Packages.
3. Right-click Packages and select DLCI Server Deployment → Import DLCI Dell Driver Cabs.
The DLCI WinPE Driver Configuration Wizard screen is displayed. If there is an existing CAB file package on the server, then
the CAB file version, Windows PE version, and architecture is displayed under CAB Selection for Import section.
4. Click Browse and navigate to the CAB file self-extractable zip file that you downloaded. Click Next.
The selected CAB file version, Windows PE version, and architecture are displayed in Cab Selection for Import section.
5. In Boot Image Selection, select any one of the following options:
NOTE: Make sure that you import a 64-bit CAB file before selecting x64 boot images in any of the following options.
Use Boot Image
from WAIK/ADK
tools
Select this option to create both x64 and x86 Dell boot images. The source for the boot image creation
is obtained from Windows Automated Installation Kit (WAIK) or Windows Assessment and Deployment
Kit (ADK), depending on the configuration, and all the Windows PE custom install packages are added
to the boot image.
Use existing Boot
Image from
Configuration
Manager
This option allows you to select an existing boot image in Configuration Manager. Select an existing
boot image from the drop-down list and use it to create a Dell boot image.
Use a custom Boot
Select this option to import a custom boot image from any other location. Specify the Universal
Naming Convention (UNC) path of the Windows Imaging (WIM) file and select the boot image from
the drop-down list.
NOTE: Only finalized images are supported if you select the Use a Custom Boot Image option for WinPE.
NOTE: The Windows PE custom boot image should have XML, Scripting, and WMI packages installed on it. For
more information on how to install these packages, see the
Microsoft Windows AIK
or
Windows ADK
documentation.
6. Click Next.
The Boot Image Property screen is displayed.
7. In the Boot Image Property, enter a name for the Dell boot image.
The Version and Comments fields are optional.
8. Click Create.
