3
Using Dell Lifecycle Controller Integration
This chapter discusses the various operations that you can perform after you install DLCI on Configuration Manager.
Before you begin using DLCI for Configuration Manager, ensure that the target system is auto-discovered and present in the All Dell
Lifecycle Controller Servers collection on the Configuration Manager console.
DLCI for Configuration Manager enables you to perform the following operations on all Dell systems under a collection:
• Configure the target systems. For more information, see Configuring target systems.
• Apply drivers on the task sequence. For more information, see Applying Drivers from the task sequence.
NOTE: Select the Apply Drivers from Lifecycle Controller check box if you want to apply drivers from Lifecycle
Controller while deploying operating systems.
• Create a task sequence media. For more information, see Creating a task sequence media bootable ISO.
• Use the System Viewer utility on specific systems in a collection. For more information, see System Viewer utility.
• Use the Config Utility on a collection of Dell systems. For more information, see Configuration utility.
• Launch the iDRAC console by right-clicking on any system discovered under All Dell Lifecycle Controller Servers on the
Configuration Manager console, or any system on the Task Viewer. For more information, see Launching the integrated Dell
Remote Access Controller console.
• Use the Task Viewer to view the status of tasks handled by DLCI for Configuration Manager. For more information, see Task
Viewer.
Licensing for DLCI
This release of DLCI is licensed. For more information on licensing; In Configuration Manager select Assets and Compliance →
Overview → Device Collections → Dell Lifecycle Controller → License Instructions.
Dell Deployment ToolKit
The Dell Deployment Toolkit (DTK) includes a set of utilities, sample scripts, and sample configuration files that you can use to
deploy and configure the Dell systems. You can use DTK to build script-based and RPM-based installation for deploying large
number of systems on a pre-operating system environment in a reliable way, without changing their current deployment processes.
Using DTK you can install operating systems on Dell systems in BIOS or Unified Extensible Firmware Interface (UEFI) mode.
NOTE: If the folders containing boot critical drivers are not present, then the wizard displays an error message.
Dell Driver CAB files
A cabinet (.cab) file is a compressed file that contains other distribution files, such as drivers and system files.
The Dell Driver CAB file provides new levels of flexibility for creating and deploying customized boot images.
Importing Dell driver files
1. Download the latest DTK file from Dell.com/support.
19
