• Edit an existing profile — to edit an existing FC HBA profile. For more information, see Editing an FC HBA profile.
4. Add new adapter port or remove an adapter port from the profile. For more information, see steps 3 through 5 in Creating an
FC HBA profile.
5. Select the adapter on the grid and configure it. For more information, see step 6 in Creating an FC HBA profile.
6. Save the FC HBA profile.
Selecting Fibre Channel storage area network in boot sequence
Once the SAN boot device is visible as a hard disk drive in the hard disk drive sequence, select the SAN boot device as the first boot
device in hard disk drive sequence of BIOS or UEFI boot sequence.
Prerequisites
For more information, see Common prerequisites.
Before changing the boot sequence, ensure that operating system is already installed and is present on the logical unit number
(LUN) assigned to the server.
About this task
The following steps outline the workflow sequence:
Steps
1. In the BIOS Configuration screen, change the boot sequence for SAN boot device as the first boot device. Click Save As
Profile
to save the updated profile. For more information, see Changing the BIOS or UEFI boot sequence and hard disk drive
sequence.
2. From the Dell Lifecycle Controller Configuration Utility, select Hardware Configuration and Operating System Deployment.
In BIOS Configuration page, select Configure BIOS, and click Browse, to select the BIOS or UEFI profile updated in step 1.
3. Select Do not deploy operating system in the advertisement screen, to skip deploying the operating system on the collection
and click
Reboot targeted collection.
4. Launch the Task Viewer, to view the status of the completed tasks. For more information, see Task Viewer.
