Before you begin
Before you begin importing the backup file to a system or collection, ensure that:
• User Data is not present in the backup image file. If you overwrite the existing configuration with the backup image file, the user
data is not restored.
• During import, operations such as firmware update, operating system deployment, and firmware configurations are not running.
• After you deploy the operating system using Lifecycle controller, the OEMDRV is open for 18 hours. If you need to perform the
operations such as update, configuration, or import after operating system deployment, remove the OEMDRV partition. To
remove the partition, reset iDRAC or cancel System Services.
Workflow for importing server profile
About this task
The following steps outline the workflow sequence:
Steps
1. To import the system profile of a single target system, launch the System Viewer utility. To import the system profiles of a
collection of systems, launch the
Config Utility. For more information, see System Viewer utility or Configuration utility.
2. Select the Platform Restore on the System Viewer utility or the Config Utility.
3. For a single system, see Importing the system profile.
4. For a collection, see Importing the system profiles in a collection.
Viewing and exporting Lifecycle Controller logs
You can view the Lifecycle Controller Logs for a single system or a collection and also export them in a .CSV format to a network
share folder. You can search and filter the Lifecycle Controller logs using Search field.
Prerequisites
• Common prerequisites
• Network Share:
– iDRAC can access the network share.
– iDRAC has the necessary permissions to write information to network share.
– Minimum free space of 384 MB is available.
• Configure the number of log files you want to view at a time in the DLCSystemview.exe.config or the
DLCConfigUtility.exe.config files. For more information, see Viewing Lifecycle Controller logs.
Before you begin
Before you begin viewing or exporting the Lifecycle Controller logs for a single system or a collection:
• If the Lifecycle Controller on the target systems is running other tasks such as firmware update, operating system deployment,
firmware configurations, exporting a system profile or importing a system profile, wait for the tasks to complete before you
retrieve the logs.
• Check the permissions on the network share and make sure the share is accessible from the Lifecycle Controller on the target
systems.
Workflow for viewing and exporting Lifecycle Controller logs
About this task
The following steps outline the workflow sequence:
16
