– Permissions and firewall settings are provided for the iDRAC to communicate with the system that has the network share.
– With a minimum free space of 384 MB available
• Administrator privileges on the iDRAC of the target systems
Before you begin
Before you begin exporting the system profile for a single system or a collection:
• Make sure that operations such as firmware update, operating system deployment, and firmware configurations are not running.
• After you deploy the operating system using Lifecycle controller, the Original Equipment Manufacturer Drive (OEMDRV) is open
for 18 hours as the Lifecycle Controller does not have the status of the operating system installation. If you need to perform the
operations such as update, configuration, or restore after you deploy the operating system, remove the OEMDRV partition. To
remove the partition, reset iDRAC or cancel System Services.
For more information on resetting iDRAC or cancelling system services, see the Dell Lifecycle Controller Remote Services User’s
Guide available at Dell.com/support/home.
• If you have scheduled the backup, then do not schedule any other remote services jobs such as BIOS updates or RAID
configuration on the target systems.
• Make sure that the backup image file is not tampered with, either during export or after export.
Workflow for exporting server profile
About this task
The following steps outline the workflow sequence:
Steps
1. To export the system profile of a single target system, launch the System Viewer utility. To export the system profiles of a
collection of systems, launch the Config Utility. For more information, see System Viewer utility or Configuration utility.
2. Select the Platform Restore on the System Viewer utility or the Config Utility.
3. For a single system, see Exporting the system profile.
4. For a collection, see Exporting the system profiles in a collection.
Importing server profile from iDRAC vFlash card or network share
You can restore the backup of a system profile for a single system or a collection of systems from an iDRAC vFlash card or a
network share using DLCI for Configuration Manager.
Prerequisites
• Common prerequisites
• iDRAC vFlash card:
– Is installed as a license, enabled and has the SRVCNF partition. In Lifecycle Controller, during backup, a partition with a label
name SRVCNF is automatically created on the vFlash SD card to store the backup image file. If a partition with the label
name SRVCNF already exists, it is overwritten. For more information, see Lifecycle Controller documentation at Dell.com/
support/manuals.
– Has minimum free space of 384 MB available.
• If you are importing from an iDRAC vFlash card, make sure that the card is installed and has the backup image in the SRVCNF
partition. This image is from the same platform that you are importing.
• If you are importing from a network share, make sure that the network share where the backup image file is stored is still
accessible.
• If you replace the motherboard before performing import, make sure that the motherboard has the latest iDRAC and BIOS
installed.
NOTE: The service tag of the server is either blank or same as when the backup was taken.
