Deploying operating system on collection
You can use DLCI for Configuration Manager to deploy an operating system on a collection of systems on the Configuration
Manager console.
Prerequisites
• Common prerequisites.
• Select the Driver CAB which is compatible with the boot image (WinPE version). You can view the DTK README to select the
correct version of the CAB file for specific WinPE or OS architecture, and provide the location of the DTK Self-Extracting
EXE. For more information, see Importing Dell driver files.
• Create a task sequence boot media for the collection of systems with an iDRAC to boot to the task sequence ISO. For more
information, see Creating a task sequence media bootable ISO.
• For prerequisites on the non-Windows operating systems deployment task, see section "Software Prerequisites and
Requirements" in the Dell Lifecycle Controller Integration for Microsoft System Center Configuration Manager Version 3.3
Installation Guide.
NOTE:
In Configuration Manager 2012, operating system deployment is not supported in UEFI boot mode. For more information,
see technet.microsoft.com/en-in/library/jj591552.aspx.
The following steps outline the workflow sequence:
1. In the Configuration Manager console, under Device Collections, right-click Managed Dell Lifecycle Controllers (OS
Unknown) and select Dell Lifecycle Controller Launch Config Utility.
2. In the Dell Lifecycle Controller Configuration Utility, select Deploy Operating System.
3. Update the firmware from a Dell repository. For more information, see Updating firmware during OS deployment.
4. Configure or edit the BIOS/NIC profiles. For more information, see Configuring hardware during OS deployment.
5. Apply FC HBA profiles and FC SAN boot attributes on a collection. For more information, see Applying FC HBA profiles and FC
SAN boot attributes on a collection.
6. Configure or edit the RAID profiles. For more information, see Configuring RAID.
7. Apply NIC/CNA profiles to the collection. For more information, see Applying a NIC or CNA profile on a collection.
8. Apply iDRAC profiles to the collection. For more information, see Applying an integrated Dell Remote Access Controller profile
on a collection.
9. Deploy the operating system and boot the systems to the media of your choice. For more information, see step 15 in Hardware
configuration and OS deployment workflow.
Exporting server profile to iDRAC vFlash card or network share
You can backup the server profile as an image file for a single system or a collection of systems by exporting the profile to an iDRAC
vFlash card or to an external source or a network share.
Prerequisites
• Common prerequisites
• Target system with valid seven character service tag
• iDRAC vFlash card:
– Installed as a license, enabled, and initialized
NOTE: The iDRAC vFlash card is required only for Dell’s 11th generation of PowerEdge servers. For the 12th and
13th generation of PowerEdge servers, you must have an Enterprise license.
– With a minimum free space of 384 MB available.
• Network Share:
