Use case scenarios
This section describes typical use cases and tasks that you can perform with DLCI for Microsoft System Center Configuration
Manager (Configuration Manager).
Common prerequisites
Before working on the user scenarios, Dell recommends that you complete the following prerequisites.
• In Configuration Manager, make sure that the system is discovered and present under Assets and Compliance → Device
Collections → All Dell Lifecycle Controller Servers. For more information, see Auto-discovery and handshake.
• Install the latest BIOS version on the system.
• Install the latest version of Lifecycle Controller on the system.
• Install the latest version of iDRAC firmware on the system.
NOTE: Always launch the Configuration Manager console with administrator privileges.
Editing and exporting the BIOS configuration profile of a system
You can edit and export the BIOS configuration of a system as a profile and apply it when you are deploying the operating system to
a collection of systems on the Configuration Manager console. For 13th generation of the Dell PowerEdge servers, you can only
view the BIOS attributes and boot sequence of currently saved boot mode.
Prerequisites
For more information, see Common prerequisites.
About this task
The following steps outline the workflow sequence:
Steps
1. Launch the System Viewer utility on the Configuration Manager console for a particular system. For more information, see
System Viewer utility.
2. Select BIOS Configuration on the System Viewer utility to load the BIOS configuration of the system. For more information,
see Viewing and editing BIOS configuration.
3. Create a profile or change an existing profile. For more information, see Creating a new profile or Editing an existing profile.
4. Add, edit, or update the attributes in the profile. For more information, see Adding a new attribute and Editing an existing BIOS
attribute.
5. (Optional) Change the BIOS or UEFI boot sequence and hard disk drive sequence. For more information, see Changing the
BIOS or UEFI boot sequence and hard disk drive sequence.
6. Save the profile as a .XML file to any folder location on the local system.
Comparing and updating the firmware inventory
You can use DLCI for Configuration Manager to compare and update the firmware inventory of a single system, or a collection of
systems. You can compare the firmware inventory against a given inventory profile, Dell FTP site, or a PDK catalog created by
Repository Manager.
