Windows Preinstallation Environment (WinPE) compatibility matrix
The following table lists the operating systems that can be deployed by DLCI for Configuration Manager and their respective WinPE
environments.
Table 3. Compatible operating systems for WinPE
Configuration Manager WinPE version Operating system
Configuration Manager Version 1610 10
• Windows Server 2012 R2
• Windows Server 2016
Configuration Manager 2012 SP2 5.0 and 10
• Windows Server 2008 R2*
• Windows Server 2012
• Windows Server 2012 R2
• Windows Server 2016
Configuration Manager 2012 R2 SP1 5.0 and 10
• Windows Server 2008 R2*
• Windows Server 2012
• Windows Server 2012 R2
• Windows Server 2016
Configuration Manager 2012 R2 5.0
• Windows Server 2008 R2*
• Windows Server 2012
• Windows Server 2012 R2
Configuration Manager 2012 SP1 4.0
• Windows Server 2008 R2*
• Windows Server 2012
Configuration Manager 2012 3.0
• Windows Server 2008
• Windows Server 2008 R2
Legend:
* — For Windows Server 2008 R2 support, visit support.microsoft.com/kb/2853726.
