Feature Functionality
System Viewer utility This feature enables you to configure individual systems by
using the remote enablement capabilities of DLCI. For more
information, see Using the System Viewer Utility.
Config Utility
This feature enables you to configure a collection of systems by
using the remote enablement capabilities of Lifecycle Controller.
For more information, see Using the Configuration Utility.
Launching the iDRAC Console This feature enables you to launch the iDRAC console from the
Task Viewer and from a system in the collection that contains
Dell’s 11th generation to 13th generation of PowerEdge systems.
For more information, see Launching the integrated Dell Remote
Access Controller console.
Support Unified Extensible Firmware Interface (UEFI) boot
mode
This feature supports configuration of UEFI boot mode and
BIOS attribute settings. For more information, see Changing the
BIOS or UEFI boot sequence and hard disk drive sequence.
Task Viewer This feature enables you to track the status of the tasks
handled by DLCI for Configuration Manager. For more
information, see Task Viewer.
Support for viewing and configuring Fibre Channel (FC) host
bus adapters (HBA) for servers
Allows you to inventory and configure FC HBA cards.
Support for configuring Storage area network (SAN) boot
attributes
Allows you to configure SAN boot attributes.
Support for exporting the system profiles before and after
hardware configuration
Allows you to back up the system profiles for a collection of
systems by exporting the profile to an iDRAC vFlash card or a
network share.
Compare the applied FC HBA profiles against the systems in a
collection and generate comparison reports
Allows you to view the comparison report between an FC HBA
profile and a selected server.
Support for ESXi 5.5 Update 3 Allows you to deploy ESXi operating systems on a collection.
Support for Red Hat Enterprise Linux (RHEL) 7.2 versions Allows you to deploy RHEL operating systems on a collection.
Supported operating systems
For information on supported operating systems, see the Dell Lifecycle Controller Integration Version 3.3 for Microsoft System
Center Configuration Manager Installation Guide at Dell.com/support/home.
Supported Microsoft .NET versions
For information on supported Microsoft .NET versions, see the Dell Lifecycle Controller Integration Version 3.3 for Microsoft
System Center Configuration Manager Installation Guide at Dell.com/support/home.
Supported target systems
For the list of supported target systems and the operating systems (Windows only) that you can deploy on the target systems, see
the Unified Server Configurator/Unified Server Configurator-Lifecycle Controller Enabled- Supported Dell Systems and Operating
Systems matrix available at Dell.com/support/home. On the Manuals page, click Software and Security → Enterprise System
Management
→ OpenManage Software. Select the OpenManage relevant release version and click the appropriate link. Click Dell
System Software Support Matrix → Dell System Software Support Matrix → View → Supported Dell Systems and Operating
Systems. In the Support Matrix, view the target systems and operating systems that are supported by Unified Server Configurator
– Lifecycle Controller Enabled.
