Inspiron 5485 2-in-1 Setup and Specifications Computer Model: Inspiron 5485 2-in-1 Regulatory Model: P93G Regulatory Type: P93G002
Notes, cautions, and warnings NOTE: A NOTE indicates important information that helps you make better use of your product. CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death. © 2019 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries.
Contents 1 Set up your Inspiron 5485 2-in-1.....................................................................................................................5 2 Create a USB recovery drive for Windows..................................................................................................... 7 3 Views of Inspiron 5485 2-in-1......................................................................................................................... 8 Right.............................................
Contacting Dell.................................................................................................................................................................
1 Set up your Inspiron 5485 2-in-1 NOTE: The images in this document may differ from your computer depending on the configuration you ordered. 1 Connect the power adapter and press the power button. NOTE: To conserve battery power, the battery might enter power saving mode. Connect the power adapter and press the power button to turn on the computer. 2 Finish Windows setup. Follow the on-screen instructions to complete the setup.
Resources Description Dell Update Updates your computer with critical fixes and latest device drivers as they become available. For more information about using Dell Update, see the knowledge base article SLN305843 at www.dell.com/support. Dell Digital Delivery Download software applications, which are purchased but not pre-installed on your computer. For more information about using Dell Digital Delivery, see the knowledge base article 153764 at www.dell.com/ support.
2 Create a USB recovery drive for Windows Create a recovery drive to troubleshoot and fix problems that may occur with Windows. An empty USB flash drive with a minimum capacity of 16 GB is required to create the recovery drive. NOTE: This process may take up to an hour to complete. NOTE: The following steps may vary depending on the version of Windows installed. Refer to the Microsoft support site for latest instructions. 1 Connect the USB flash drive to your computer. 2 In Windows search, type Recovery.
3 Views of Inspiron 5485 2-in-1 Right 1 SD-card slot Reads from and writes to the SD card. 2 USB 2.0 port Connect peripherals such as external storage devices and printers. Provides data transfer speeds up to 480 Mbps. 3 Security-cable slot (wedge-shaped) Connect a security cable to prevent unauthorized movement of your computer. Left 1 Power-adapter port Connect a power adapter to provide power to your computer.
Supports Power Delivery that enables two-way power supply between devices. Provides up to 7.5 W power output that enables faster charging. NOTE: The Dell Adapter USB-C to USB-A 3.0 is shipped with this computer. Use this adapter to connect legacy USB 3.0 accessories to USB (Type-C) ports on your computer. NOTE: A USB Type-C to DisplayPort adapter (sold separately) is required to connect a DisplayPort device. 4 HDMI port Connect to a TV or another HDMI-in enabled device. Provides video and audio output.
NOTE: You can customize power-button behavior in Windows. For more information, see Me and My Dell at www.dell.com/support/manuals. Display 1 Left microphone Provides digital sound input for audio recording and voice calls. 2 Camera Enables you to video chat, capture photos, and record videos. 3 Camera-status light Turns on when the camera is in use. 4 Right microphone Provides digital sound input for audio recording and voice calls.
Bottom 1 Left speaker Provides audio output. 2 Service Tag label The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in your computer and access warranty information. 3 Right speaker Provides audio output.
Tablet Stand Tent 12 Views of Inspiron 5485 2-in-1
4 Specifications of Inspiron 5485 2-in-1 Dimensions and weight Table 2. Dimensions and weight Description Values Height: Front 19.74 mm (0.78 in.) Rear 19.95 mm (0.79 in.) Width 328 mm (12.91 in.) Depth 232.80 mm (9.17 in.) Weight 1.85 kg (4.08 lb) NOTE: The weight of your computer depends on the configuration ordered and the manufacturing variability. Processors Table 3.
Chipset Table 4. Chipset Description Values Chipset Integrated into the processor Processor • • • • AMD Athlon 300U Mobile Processor AMD Ryzen 3 3200U Mobile Processor AMD Ryzen 5 3500U Mobile Processor AMD Ryzen 7 3700U Mobile Processor DRAM bus width 64-bit Flash EPROM 16 MB PCIe bus Up to PCIe Gen3 Operating system • Windows 10 Home (64-bit) • Windows 10 Professional (64-bit) Memory Table 5.
Ports and connectors Table 6. External ports and connectors External: USB • • • One USB 2.0 port Two USB 3.1 Gen 1 port One USB 3.1 Type-C port with PowerDelivery/DisplayPort Audio One headset port Video One HDMI 1.4b port Media card reader One SD-card slot Docking port Not supported Power adapter port Not supported Security Wedge-shaped lock Table 7. Internal ports and connectors Internal: M.2 • • One M.2 slot for WiFi and Bluetooth combo card One M.2 slot for M.2 2280 or M.
Description Values • • AES-CCMP TKIP • • Bluetooth 4.2 Bluetooth AES-CCMP TKIP Bluetooth 4.2 NOTE: Windows 10 supports up to Bluetooth 4.2 with the latest Windows update. NOTE: Windows 10 supports up to Bluetooth 4.2 with the latest Windows update. Audio Table 9.
Table 10. Storage specifications Storage type Interface type Capacity 2.5-inch hard drive SATA AHCI 6 Gbps Up to 2 TB M.2 2230/2280 solid-state drive PCIe NVMe up to 16 Gbps Up to 512 GB Media-card reader Table 11. Media-card reader specifications Description Values Type One SD-card slot Cards supported • • • Secure Digital (SD) Secure Digital High Capacity (SDHC) Secure Digital Extended Capacity (SDXC) Keyboard Table 12.
Camera Table 13. Camera specifications Description Values Number of cameras One Type HD fixed focus Location Front camera Sensor type CMOS sensor technology Resolution: Still image 0.92 megapixel (HD) Video 1280 x 720 (HD) at 30 fps 78.6 degrees Diagonal viewing angle Touchpad Table 14. Touchpad specifications Description Values Resolution: Horizontal 1229 Vertical 929 Horizontal 105 mm (4.13 in.) Vertical 65 mm (2.56 in.
Power adapter Table 15. Power adapter specifications Description Values Type 45 W Diameter (connector) 4.5 mm Input voltage 100 VAC–240 VAC Input frequency 50 Hz–60 Hz Input current (maximum) 1.30 A Output current (continuous) 2.31 A Rated output voltage 19.50 VDC Temperature range: Operating 0°C to 40°C (32°F to 104°F) Storage –40°C to 70°C (–40°F to 158°F) Battery Table 16. Battery specifications Description Values Type 3-cell Primus (42 WHr) Voltage 11.
Description Values NOTE: Control the charging time, duration, start and end time, and so on using the Dell Power Manager application. For more information on the Dell Power Manager see, Me and My Dell on https://www.dell.com/. Life span (approximate) 300 discharge/charge cycles Coin-cell battery CR-2032 Operating time Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions. Display Table 17.
Fingerprint reader (optional) Table 18. Fingerprint reader specifications Description Values Sensor technology Capacitive Sensor resolution 108 pixels x 88 pixels Sensor area 5.5 mm x 4.5 mm Sensor pixel size 114 x 114 pixels Video Table 19. Video specifications Integrated graphics Controller External display support Memory size Radeon Vega 3 Graphics One HDMI 1.4b port and one USB 3.
‡ Measured using a 2 ms half-sine pulse when the hard-drive head is in parked position.
5 Keyboard shortcuts NOTE: Keyboard characters may differ depending on the keyboard language configuration. Keys used for shortcuts remain the same across all language configurations. Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. The symbol shown on the lower part of the key refers to the character that is typed out when the key is pressed.
Table 22.
6 Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 23. Self-help resources Self-help resources Resource location Information about Dell products and services www.dell.com My Dell Tips Contact Support In Windows search, type Contact Support, and press Enter. Online help for operating system www.dell.com/support/windows www.dell.
