Using iDRAC Service Module, you can reduce the number of manual steps required to collect the Dell Technical Support Report
as the collection process is automated.
Data to Collect
SupportAssist automatically creates and sends a collection to Dell Technical Support when there is an event-based trigger or
where you have configured a scheduled cadence. You can collect the following type of information:
● System Information
● Storage Logs
● OS and Application Data
● Debug Logs
You can also perform the SupportAssist Collection function from an operating system shell to a specified file path using:
./ Invoke-SupportAssistCollection [--filepath/-f]
NOTE: This shell command is only supported on iDRAC9 in the yx4x and later PowerEdge servers and if logged into the
operating system as an administrator.
NOTE: On Windows Core operating system, you must go to the absolute path to run the Invoke-
SupportAssistCollection.exe command.
Collection preferences
You can select or set the collection preferences using the collection preferences feature. You can select any of the following
types of collection preferences to save collection reports:
● Send Now—You will get a notification that The job has been successfully added to the job queue after you click the
Collect option.
● Save Locally
● Save to Network—If you select this option, you must provide Network Settings details such as Protocol, IP Address,
Share Name, Domain Name, User Name, and Password.
You can select any of the collection preferences and click Collect to receive the data.
NOTE:
This feature is available by default when you install iDRAC Service Module 2.0 or later versions on systems running
supported Microsoft or Linux operating systems. You cannot disable the feature.
NOTE: The operating system log file collection feature of Automatic SupportAssist Collection is not supported on CentOS.
NOTE: The operating system and application data collection on ESXi is supported by yx4x and later PowerEdge servers
only.
Anonymous collection of reports
You can perform SupportAssist Collection and upload operations without completing the registration process. Until iDRAC
Service Module version 3.0.2, the registration was a prerequisite to perform SupportAssist Collection.
The supported iDRAC firmware for the anonymous collection is iDRAC 3.15.15.15 in the yx4x and yx5x PowerEdge servers and
2.60.60.60 in the yx3x PowerEdge servers.
NOTE:
You can perform Anonymous SupportAssist Collection upload using a blank username or password in a proxy
environment on the yx3x PowerEdge servers.
Correlation of software events to hardware failures for Microsoft SDS
The event log files for hardware storage pool alerts or events are monitored by iSM with the server storage correlation feature.
The server storage subsystem is monitored when Dell EMC storage controllers are used in RAID mode. But in Storage Spaces
(SS) or Storage Space Direct (S2D), the server storage subsystem is monitored in a passthru mode, or the SATA chipset is used
to create the storage pool. With this feature, hardware-defined alerts that are covered by the Lifecycle Controller (LC) log and
