Table 2. Supported platforms on iDRAC Service Module
yx5x PowerEdge servers yx4x PowerEdge servers yx3x PowerEdge servers yx2x PowerEdge servers
R640 T630
R740
R740xd
R940
T440
T640
Coexistence of OpenManage Server Administrator and
iDRAC Service Module
OpenManage Server Administrator (OMSA) and iDRAC Service Module (iSM) can coexist on a single system. If you enable the
monitoring features during the iSM installation, and, after the installation is complete, if the iSM detects the presence of OMSA,
iSM disables the AutoSystemRecovery and Lifecycle Log Replication features that overlap. If the OMSA service stops, the iSM
features that had been disabled are enabled.
NOTE: The overlapping features are AutoSystemRecovery and Lifecycle Log Replication.
Software availability
iDRAC Service Module software is available on:
● Dell EMC OpenManage Systems Management Tools and Documentation DVD
● Dell.com/support
Downloading iSM
To download the iSM:
1. Go to Dell.com/support.
2. In the support site, click Browse all products > Software > Enterprise Systems Management > Remote Enterprise
Systems Management > iDRAC Service Module > iDRAC Service Module - Current Versions > Drivers and
Downloads.
Accessing support content from the Dell EMC support
site
Access supporting content related to an array of systems management tools using direct links, going to the Dell EMC support
site, or using a search engine.
● Direct links:
○ For Dell EMC Enterprise Systems Management and Dell EMC Remote Enterprise Systems Management—https://
www.dell.com/esmmanuals
○ For Dell EMC Virtualization Solutions—https://www.dell.com/SoftwareManuals
○ For Dell EMC OpenManage—https://www.dell.com/openmanagemanuals
○ For iDRAC—https://www.dell.com/idracmanuals
○ For Dell EMC OpenManage Connections Enterprise Systems Management—https://www.dell.com/
OMConnectionsEnterpriseSystemsManagement
○ For Dell EMC Serviceability Tools—https://www.dell.com/serviceabilitytools
8
