Table 1. Features supported by each supported operating system
Features Servers Operating systems
Supported PowerEdge series Microsoft Windows
(including HyperV
systems)
Linux Virtualization
(VMware ESXi)
Sharing operating
system information
yx2x, yx3x, yx4x, yx5x Yes Yes Yes
Lifecycle Controller
Log replication
yx2x, yx3x, yx4x, yx5x Yes Yes Yes
Automatic system
recovery/watchdog
yx2x, yx3x, yx4x, yx5x Yes Yes Yes
Windows
Management
Instrumentation
Providers
yx2x, yx3x, yx4x, yx5x Yes NA NA
Prepare to remove
NVMe device
through iDRAC.
yx3x, yx4x, yx5x Yes Yes Yes
SupportAssist
collection from host
operating system
yx2x, yx3x, yx4x, yx5x Yes Yes Yes
Operating system
and application data
yx2x, yx3x, yx4x, yx5x Yes Yes
Yes (only for yx4x
and later PowerEdge
servers)
Remote iDRAC hard
reset
yx2x, yx3x, yx4x, yx5x Yes Yes Yes
iDRAC access via
Host OS
yx2x, yx3x, yx4x, yx5x Yes Yes NA
In-Band support for
iDRAC SNMP alerts
yx2x, yx3x, yx4x, yx5x Yes Yes Yes
Network interface
monitoring support
through Redfish
client
yx2x, yx3x, yx4x, yx5x Yes Yes Yes
Enable WS-Man
remotely.
yx2x, yx3x, yx4x, yx5x Yes NA NA
FullPowerCycle yx4x, yx5x Yes Yes
VMware ESXi 7.x :
Yes
In-Band SNMP get yx2x, yx3x, yx4x, yx5x Yes Yes NA
Live VIB installation yx3x, yx4x, yx5x NA NA Yes
SupportAssist-
anonymous collection
report
yx2x, yx3x, yx4x, yx5x Yes Yes Yes
iDRAC UI launcher yx3x, yx4x, yx5x Yes Yes NA
IPv6 support yx3x, yx4x, yx5x Yes Yes NA
Auto dispatch for
selective events
yx4x, yx5x Yes Yes Yes
SupportAssist
collection with
selective PII
yx2x, yx3x, yx4x, yx5x Yes Yes Yes
6 Introduction
