lower power state, similar to removing and replacing AC. The flag can be cleared using the Cancel function anytime the system
is in the S0 state prior to the system entering the S5 state.
You can avail different options of FullPowerCycle on your system. Use the following commands to request, get status, and
cancel the FullPowerCycle on your system:
For Windows Operating systems, shortcut menus are available for the FullPowerCycle Activate (request), FullPowerCycle
Cancel and FullPowerCycle get status operations.
Table 13.
Commands to run in the power shell console Descriptions
Invoke-FullPowerCycle —status request
To request FullPowerCycle on your system.
NOTE: A message is displayed that the VirtualAC Power
Cycle operation is triggered by the server operating
system.
Invoke-FullPowerCycle -status Get
To get the status of the FullPowerCycle on your system.
NOTE: A message is displayed that the system is going
for turn off at the scheduled date and time.
Invoke-FullPowerCycle -status cancel
To cancel the FullPowerCycle on your system.
/opt/dell/srvadmin/iSM/bin/Invoke-
FullPowerCycle request
To request FullPowerCycle on Linux operating system.
/opt/dell/srvadmin/iSM/bin/Invoke-
FullPowerCycle cancel
To cancel FullPowerCycle on Linux operating system
/opt/dell/srvadmin/iSM/bin/Invoke-
FullPowerCycle get-status
To get FullPowerCycle status on Linux operating system
The following messages are displayed after each successful FullPowerCycle operation on operating system log files and LCL:
Request message:"The Full Power Cycle operation is triggered by the server operating system
(OS) user <user name> from the OS on date <date>. However, the server components will be AC
power cycled when the server is shut down".
Cancel Message: "The Full Power Cycle operation is successfully cancelled by the server
operating system (OS) user <user name> from the OS on date <date>".
NOTE: The FullPowerCycle feature is available for ESXi 7.x operating system, but not for ESXi 6.x operating systems.
NOTE: The FullPowerCycle feature can be used only with local or domain administrator, or root or sudo users.
SupportAssist on the box
SupportAssist saves time and streamlines technical support cases. A collection based on an event creates an open service
request with SupportAssist. Scheduled collections help to monitor and maintain your environment. These collections include
hardware information data, RAID controller log files, operating system, and application data. The features that are supported
are :
● SupportAssist Registration—iSM supports SupportAssist Registration. This is a one time activity. You can enter the
required details such as name, email, address, and number to complete the registration.
● SupportAssist Collection—The SupportAssist Collection feature in iDRAC collects information about the hardware,
operating system, and relevant application data and compresses this information.
SupportAssist also provides:
● Proactive issue identification
● Automated case creation
● Support contact initiated by a Dell technical support agent
NOTE: You must complete the registration to take advantage of SupportAssist.
You can view the following items in the SupportAssist dashboard.
34
