Configuring iDRAC Servcie Module
iDRAC Service Module features can be configured remotely using various iDRAC interfaces such as UI, CLI, and WS-Man.
Topics:
• Configuring iDRAC Service Module from iDRAC web interface
• Configuring iDRAC Service Module from RACADM
• Configuring iDRAC Service Module from WS-Man
Configuring iDRAC Service Module from iDRAC web
interface
Log in to iDRAC UI using the iDRAC IP address as a root or administrator user.
To use iSM from the iDRAC web interface for yx2x and yx3x PowerEdge servers, go to Overview > Server > Service Module.
To use the iSM from the iDRAC web interface for yx4x and yx5x PowerEdge servers, go to iDRAC settings > Settings >
iDRAC Service Module setup.
Configuring iDRAC Service Module from RACADM
iSM can be accessed and configured through RACADM CLI commands. To verify the status of the features that are provided by
iSM, use the racadm get idrac.servicemodule command. The features are:
● ChipsetSATASupported
● HostSNMPAlert
● HostSNMPGet
● iDRACHardReset
● iDRACSSOLauncher
● LCLReplication
● OSInfo
● ServiceModuleEnable
● SSEventCorrelation
● WatchdogRecoveryAction
● WatchdogResetTime
● WatchdogState
● WMIInfo
To set or configure the features, use the command racadm set idrac.servicemodule. <feature name>
<enabled or disabled>.
NOTE: Feature names and attributes that start with a # symbol cannot be modified.
To use iSM from RACADM, see the objects in the Service Module group in the RACADM Command Line Reference Guide for
iDRAC8, iDRAC9, and CMC available at Dell.com/support.
