Linux install dependencies
The following are the list of dependent packages and executables that need to be installed to complete the installation.
Table 8. Linux install dependencies
Executable commands Package name
/sys fileSystem
grep grep
cut, cat, echo, pwd, coreutils
lsusb usbutils
find findutils
shell script commands bash
ifconfig net-tools
ping Iputils
chkconfig
Red Hat Enterprise Linux
● chkconfig
SUSE Linux Enterprise Server
● aaa_base
install_initd
Red Hat Enterprise Linux
● redhat-lsb-core
SUSE Linux Enterprise Server
● insserv
systemctl systemd
curl libcurl
openssl libssl
Installing the iDRAC Service Module on Linux operating systems
1. The available features that can be installed are displayed on the screen:
● [1] Watchdog Instrumentation Service
● [2] LifeCycle Log Information
● [3] Operating System Information
● [4] iDRAC access via Host OS
○ [a] Access via GUI, WS-man, Redfish, Remote RACADM
○ [b] In-Band SNMP Traps
○ [c] Access via SNMP Get
● [5] iDRAC SSO Launcher
○ [a] Read only
○ [b] Administrator
● [6] Chipset S.M.A.R.T Monitoring
● ○ [a] Periodic S.M.A.R.T Log Collection
● [7] iDRAC Hard Reset
● [8] SupportAssist
● [9] Full Power Cycle
● [10] All features
2. To install the required feature, type the number of the respective feature. Separate the number of the features to be
installed by a comma. For example, to install the subfeatures, type 4.a, 4.b or 4.c.
