NOTE: You can also uninstall by selecting Uninstall after running the iDRACSvcMod.msi command.
NOTE: You can view the iSM log files in the Application group of the Windows Logs folder in the Windows Event
Viewer.
Installing the iDRAC Service Module on VMware ESXi
VMware ESXi is factory-installed on some systems. For a list of these systems, see the latest Systems Software Support Matrix
at dell.com/support.
iSM is available in a ZIP file for installing on systems running VMware ESXi. The ZIP file follows the naming convention
ISM-Dell-Web-3.6.0-<bldno>.VIB-<version>i-Live.zip, where <version> is the supported ESXi version.
The ZIP files for the supported ESXi versions are:
● For VMware ESXi 7.x: ISM-Dell-Web-3.6.0-<bldno>.VIB-ESX7i-Live.zip
● For VMware ESXi 6.x: ISM-Dell-Web-3.6.0-<bldno>.VIB-ESX6i-Live.zip
If VMware ESXi is not installed on your system, follow these steps to install iSM on VMware ESXi:
1. Copy iSM offline bundle ZIP file to the /var/log/vmware location on the host operating system.
2. Run the following command:
● For VMware ESXi 7.x: esxcli software component apply -d /var/log/vmware/<iDRAC Service
Module file>
● For VMware ESXi 6.x: esxcli software vib install -d /var/log/vmware/<iDRAC Service Module
file>
To upgrade the iSM on VMware ESXi, do the following:
1. Copy the iSM offline bundle ZIP file to the /var/log/vmware location on the host operating system.
2. Run the following command:
● For VMware ESXi 7.x: esxcli software component apply -d /var/log/vmware/<iDRAC Service
Module file>
● For VMware ESXi 6.x: esxcli software vib update -d /var/log/vmware/<iDRAC Service Module
file>
NOTE:
The feature configuration of iDRAC Service Module is not retained as is after a forced or ungraceful reboot. A
backup of the configuration files is created by the ESXi hypervisor through the script /sbin/auto-backup.sh that
runs periodically every 60 minutes. If you want to retain the configuration, manually run the backup.sh script before you
reboot the system.
NOTE: Reboot of the host operating system is not required after installing or uninstalling the iDRAC Service Module Live
VIB package.
NOTE: On repository-based installs such as VMware Update Manager (VUM) and apt-repository, not all features are
enabled by default.
Download VMware vSphere Command Line Interface (vSphere CLI) from http://vmwaredepot.dell.com/DEL/ and install on
your Microsoft Windows or Linux system.
Using the vSphere CLI
To install the iSM software on VMware ESXi using the vSphere CLI:
1. Copy the ISM-Dell-Web-3.6.0-<bldno>.VIB-<version>i-Live.zip file to a directory on the system.
2. Shut down all guest operating systems on the ESXi host and put the ESXi host in maintenance mode.
3. If you are using vSphere CLI on Windows, go to the directory where you have installed the vSphere CLI utilities. If you are
using vSphere CLI on Linux, run the following command from any directory:
For VMware ESXi 7.x:
esxcli --server <IP Address of ESXi 7.x host> software component apply -d /var/log/
vmware/<iDRAC Service Module file>
