Table 3. Supported platforms on Linux operating systems
Dell EMC devices Ubuntu 20.04 SUSE Linux
Enterprise Server 15
SP2
Red Hat Enterprise
Linux 8.3
Red Hat Enterprise
Linux 7.9
yx5x PowerEdge servers Yes Yes Yes Yes
yx4x PowerEdge servers Yes Yes Yes Yes
yx3x PowerEdge servers No Yes Yes Yes
yx2x PowerEdge servers No No No No
NOTE: Limited yx3x PowerEdge servers support the Red Hat Enterprise Linux 8.0 operating system. For the list of
supported Dell EMC servers, see https://linux.dell.com/files/supportmatrix/RHEL_Support_Matrix.pdf.
Supported platforms on Microsoft Windows operating systems
The table lists the platforms that are supported by iDRAC Service Module 3.6 on Microsoft Windows operating systems.
Table 4. Supported platforms on Microsoft Windows operating systems
Dell EMC devices Microsoft Windows Server 2019 Microsoft Windows Server 2016
yx5x PowerEdge servers Yes Yes
yx4x PowerEdge servers Yes Yes
yx3x PowerEdge servers Yes Yes
yx2x PowerEdge servers No Yes
Supported platforms on virtualization hypervisor
The table lists the platforms that are supported by iSM 3.6 on virtualization operating systems.
Table 5. Supported platforms on virtualization hypervisor
Dell EMC PowerEdge servers
VMware ESXi
vSphere 7.0 U1 and 7.0 U2 vSphere 6.7 U3
yx5x PowerEdge servers Yes Yes
yx4x PowerEdge servers Yes Yes
yx3x PowerEdge servers Yes* Yes
yx2x PowerEdge servers No No
* - Only few yx3x PowerEdge servers support VMware ESXi 7.0 U1 and 7.0 U2. To know the list of supported yx3x PowerEdge
servers, see VMware vSphere 7.x on Dell EMC PowerEdge Servers Compatibility Matrix.
Supported operating systems on Dell EMC Precision Rack System
Table 6. Supported operating systems on Dell EMC Precision Rack System
Dell EMC devices Microsoft Windows 10 RS5
R7920 Yes
