Dell HPC NFS Storage Solution - High Availability Configurations
Page 24
Figure 10 - 10GbE Large Sequential Write Performance
Figure 11 - 10GbE Large Sequential Read Performance
A single NFS client with a 10 Gigabit Ethernet connection to the NFS server was tested as well. In
this case the NFS client had only a 10 Gigabit Ethernet card (and no InfiniBand card). Both the NFS
client and the NSS server were directly connected to the PowerConnect 8024 10 Gigabit Ethernet
0
200
400
600
800
1000
1200
1400
1 2 4 8 16 32 48 64
Throughput: MB/sec
Number of clients
10GbE Large sequential writes
Large Medium
0
200
400
600
800
1000
1200
1400
1 2 4 8 16 32 48 64
Throughput: MB/sec
Number of clients
10GbE Large sequential reads
Large Medium
