The show running config vpc command can be used to filter the running configuration to show
only vPC related settings.
Nx5672-1
x5672-1# show running-config vpc
!Command: show running-config vpc
!Time: Sun Feb 17 21:06:03 2002
version 7.0(1)N1(1)
feature vpc
vpc domain 1
role priority 1
peer-keepalive destination 172.25.109.24
delay restore 150
auto-recovery
interface port-channel55
vpc peer-link
interface port-channel100
vpc 100
interface port-channel200
vpc 200
