87 PowerEdge FX2 – FN I/O Module – VLT Deployment Guide | Version 2.2
input rate 1.60 Gbps, 143.70 Kpps; output rate 5.37 Gbps,
479.12 Kpps
RX
644993875 unicast packets 1646 multicast packets 88 broadcast
packets
644995613 input packets 901181970961 bytes
0 jumbo packets 0 storm suppression bytes
0 runts 0 giants 0 CRC 0 no buffer
0 input error 0 short frame 0 overrun 0 underrun 0 ignored
0 watchdog 0 bad etype drop 0 bad proto drop 0 if down drop
0 input with dribble 0 input discard
0 Rx pause
TX
1959105966 unicast packets 21150 multicast packets 123
broadcast packets
1959127229 output packets 2745782142132 bytes
0 jumbo packets
0 output error 0 collision 0 deferred 0 late collision
0 lost carrier 0 no carrier 0 babble 0 output discard
0 Tx pause
5 interface resets
