85 PowerEdge FX2 – FN I/O Module – VLT Deployment Guide | Version 2.2
Nx5672-1
5548-1# show vpc brief
Legend:
(*) - local vPC is down, forwarding via vPC peer-link
vPC domain id : 1
Peer status : peer adjacency formed ok
vPC keep-alive status : peer is alive
Configuration consistency status : success
Per-vlan consistency status : success
Type-2 consistency status : success
vPC role : primary
Number of vPCs configured : 2
Peer Gateway : Disabled
Dual-active excluded VLANs : -
Graceful Consistency Check : Enabled
Auto-recovery status : Enabled (timeout = 240 seconds)
vPC Peer-link status
---------------------------------------------------------------------
id Port Status Active vlans
-- ---- ------ --------------------------------------------------
1 Po55 up 1
vPC status
---------------------------------------------------------------------------
-
id Port Status Consistency Reason Active
vlans
------ ----------- ------ ----------- -------------------------- ----------
-
