84 PowerEdge FX2 – FN I/O Module – VLT Deployment Guide | Version 2.2
9.4 Environment Four: Verify VPC connectivity
Use the following commands (Table 15) to verify that the vPC configuration is valid.
vPC show commands used to verify the vPC configuration
Command
Purpose
show feature
Reports if vPC is enabled or not
show vpc brief
Displays brief information about the vPCs
show interface port-channel
Displays vPC status and vPC number of the port
channel
show running-config vpc
Displays running configuration for vPCs
show vpc peer-keepalive
Displays information about the peer-keepalive
The output of the show feature command shown below has been passed to grep and filtered for
any enabled features. The results show that lacp and vpc are both enabled.
Nx5672-1
Nx5672-1# show feature | grep enabled
lacp 1 enabled
lldp 1 enabled
sshServer 1 enabled
telnetServer 1 enabled
vpc 1 enabled
Show vpc brief gives a quick verification that the vPC domain is functioning. The important point to
note in the output of this command are Configuration, Per-vlan and Type-2 consistency
all show the status of success.
