Example of show mac-address-table on switch S4810-2.
S4810-2
S4810-2#show mac-address-table
Codes: *N - VLT Peer Synced MAC
VlanId Mac Address Type Interface
State
1 00:01:e8:8b:36:10 Dynamic (N) Po 111
Active
1 00:18:8b:a2:cb:3b Dynamic (N) Po 111
Active
1 00:1e:c9:de:01:70 Dynamic (N) Po 124
Active
1 00:1e:c9:de:01:78 Dynamic (N) Po 124
Active
1 18:a9:9b:d9:28:81 Dynamic (N) Po 124
Active
1 18:a9:9b:d9:2f:27 Dynamic (N) Po 124
Active
