67 PowerEdge FX2 – FN I/O Module – VLT Deployment Guide | Version 2.2
Example of show mac-address-table on switch S4810-1.
S4810-1
S4810-1#show mac-address-table
Codes: *N - VLT Peer Synced MAC
VlanId Mac Address Type Interface
State
1 00:01:e8:8b:36:10 Dynamic Po 111
Active
1 00:18:8b:a2:cb:3b Dynamic Po 111
Active
1 00:1e:c9:de:01:70 Dynamic Po 123
Active
1 00:1e:c9:de:01:78 Dynamic Po 123
Active
1 18:a9:9b:d9:28:81 Dynamic Po 123
Active
1 18:a9:9b:d9:2f:27 Dynamic Po 123
Active
