65 PowerEdge FX2 – FN I/O Module – VLT Deployment Guide | Version 2.2
Example of show mac-address-table on switch FN410S-A2.
FN410S-A2
FN410S-A2#show mac-address-table
Codes: *N - VLT Peer Synced MAC
VlanId Mac Address Type Interface
State
1 00:01:e8:8b:32:4a Dynamic Po 122
Active
1 00:01:e8:8b:34:db Dynamic Po 122
Active
1 00:18:8b:a2:cb:3b Dynamic Po 122
Active
1 18:a9:9b:d9:28:81 Dynamic (N) Po 101
Active
1 18:a9:9b:d9:28:84 Dynamic (N) Po 101
Active
1 18:a9:9b:d9:2f:27 Dynamic Po 104
Active
1 18:a9:9b:d9:2f:2a Dynamic Po 104
Active
