49 PowerEdge FX2 – FN I/O Module – VLT Deployment Guide | Version 2.2
Example of show vlt brief on switch S4810-2.
S4810-2
S4810-2#show vlt brief
VLT Domain Brief
------------------
Domain ID: 2
Role: Secondary
Role Priority: 2
ICL Link Status: Up
HeartBeat Status: Up
VLT Peer Status: Up
Local Unit Id: 1
Version: 6(2)
Local System MAC address: 00:01:e8:8b:34:d9
Remote System MAC address: 00:01:e8:8b:32:48
Remote system version: 6(2)
Delay-Restore timer: 90 seconds
Peer-Routing : Disabled
Peer-Routing-timeout timer: 0 seconds
Multicast peer-routing timeout: 150 seconds
Example of show vlt detail on switch S4810-2.
S4810-2
S4810-2#show vlt detail
Local LAG Id Peer LAG Id Local Status Peer Status Active
VLANs
------------ ----------- ------------ ----------- --------
-----
111 111 UP UP 1
124 123 UP UP 1
