45 PowerEdge FX2 – FN I/O Module – VLT Deployment Guide | Version 2.2
Example of show vlt brief on switch FN410S-A2.
FN410S-A2
FN410S-A2#show vlt brief
VLT Domain Brief
------------------
Domain ID: 1
Role: Primary
Role Priority: 32768
ICL Link Status: Up
HeartBeat Status: Up
VLT Peer Status: Up
Local Unit Id: 1
Version: 6(2)
Local System MAC address: 00:1e:c9:de:01:72
Remote System MAC address: 00:1e:c9:de:01:7a
Remote system version: 6(2)
Delay-Restore timer: 90 seconds
Peer-Routing : Disabled
Peer-Routing-Timeout timer: 0 seconds
Multicast peer-routing timeout: 150 seconds
Example of show vlt detail on switch FN410S-A2.
FN410S-A2
FN410S-A2#show vlt detail
Local LAG Id Peer LAG Id Local Status Peer Status
Active VLANs
------------ ---------- ------------ ----------- -----
--------
101 101 UP UP 1
104 103 UP UP 1
122 121 UP UP 1
