41 PowerEdge FX2 – FN I/O Module – VLT Deployment Guide | Version 2.2
management IP (management IP of
the other switch)
(management IP of the other
switch)
vlt domain 2
peer-link port-channel 55
back-up destination
172.25.190.38
unit-id 0
exit
vlt domain 2
peer-link port-channel
55
back-up destination
172.25.190.37
unit-id 1
exit
Configure the port channel
Configure the port channels member
interfaces
Configure the port channel
Configure the port channels
member interfaces
int port-channel 121
description “Port Channel
to IOM Pair”
Portmode hybrid
Switchport
vlt-peer-lag po121
no shutdown
exit
interface range te0/1-2
description “Portchannel
link to IOM”
no switchport
port-channel-protocol lacp
port-channel 121 mode
active
exit
no shutdown
int port-channel 121
description “Port
Channel to IOM Pair”
Portmode hybrid
Switchport
vlt-peer-lag po121
no shutdown
exit
interface range te0/1-2
description
“Portchannel link to
IOM”
no switchport
port-channel-protocol
lacp
port-channel 121 mode
active
exit
no shutdown
S4810 VLT configuration
