38 PowerEdge FX2 – FN I/O Module – VLT Deployment Guide | Version 2.2
FN410S- A1
FN410S- A2
Configure the peer LAG, and then
configure upstream links for the
mVLT connection
Create the port channel.
Configure the peer LAG, and
then configure upstream links
for the mVLT connection.
Create the port channel.
interface port-channel 101
description “PO to CNA NIC
1”
portmode hybrid
switchport
vlt-peer-lag po101
no shutdown
exit
interface port-channel
101
description “PO to
CNA NIC 1”
portmode hybrid
switchport
vlt-peer-lag po101
no shutdown
exit
Configure the internal port and set
the port channel.
Configure the internal port
and set the port channel.
interface te0/1
no switchport
port-channel-protocol lacp
port-channel 101 mode
active
exit
no shutdown
interface te0/1
no switchport
port-channel-protocol
lacp
port-channel 101
mode active
exit
no shutdown
Configure the port channel for
upstream links.
Configure the port channel for
upstream links.
interface port-channel 121
description “PO to Dell
S4810”
portmode hybrid
switchport
vlt-peer-lag po121
no shutdown
exit
interface port-channel
121
description “PO to
Dell S4810”
portmode hybrid
switchport
vlt-peer-lag po121
no shutdown
exit
Configure the interfaces that will
participate in the VLT port channel.
Configure the interfaces that
will participate in the VLT port
channel.
