103 PowerEdge FX2 – FN I/O Module – VLT Deployment Guide | Version 2.2
Cisco NX-OS Release 7
Nx5548(config)# interface Ethernet 1/1-4
Nx5548(config-if-range)# switchport mode trunk
Nx5548(config-if-range)# channel-group 10 mode active
Nx5548(config-if-range)# no shut
Nx5548(config-if-range)# interface port-channel 10
Nx5548(config-if)# switchport mode trunk
Nx5548(config-if)# no shut
Cisco Nexus 5548 port channel configuration
Brocade Network OS 4.X
VDX(config)# interface TenGigabitEthernet 10/0/1-4
VDX(conf-if-te-10/0/1-4)# channel-group 128 mode active type
standard
VDX(conf-if-te-10/0/1-4)# no shut
VDX(config)# interface Port-channel 128
VDX(config-Port-channel-128)# switchport
VDX(config-Port-channel-128)# switchport mode trunk
VDX(config-Port-channel-128)# no shut
Brocade VDX6730 port channel configuration
