E2 - OSPF external type 2, * - candidate default,
+ - summary route, > - non-active route
Gateway of last resort is not set
Destination Gateway Dist/Metric Last Change
--------------------------------------------------------------------------------
O E2 10.0.1.1/32 via 192.168.1.0 ethernet1/1/25 110/20 00:15:34
O E2 10.0.1.2/32 via 192.168.2.0 ethernet1/1/26 110/20 00:15:27
O E2 10.0.2.2/32 via 192.168.1.0 ethernet1/1/25 110/20 00:15:27
via 192.168.2.0 ethernet1/1/26
O E2 10.0.2.3/32 via 192.168.1.0 ethernet1/1/25 110/20 00:15:27
via 192.168.2.0 ethernet1/1/26
O E2 10.0.2.4/32 via 192.168.1.0 ethernet1/1/25 110/20 00:15:27
via 192.168.2.0 ethernet1/1/26
O E2 10.60.1.0/24 via 192.168.1.0 ethernet1/1/25 110/20 00:15:27
via 192.168.2.0 ethernet1/1/26
O 192.168.1.2/31 via 192.168.1.0 ethernet1/1/25 110/2 00:15:34
O 192.168.1.4/31 via 192.168.1.0 ethernet1/1/25 110/2 00:15:34
O 192.168.1.6/31 via 192.168.1.0 ethernet1/1/25 110/2 00:15:34
O 192.168.2.2/31 via 192.168.2.0 ethernet1/1/26 110/2 00:15:27
O 192.168.2.4/31 via 192.168.2.0 ethernet1/1/26 110/2 00:15:27
O 192.168.2.6/31 via 192.168.2.0 ethernet1/1/26 110/2 00:15:27
Note: The command show ip route <cr> can also be used to verify the information above as well as
static routes and direct connections.
6.3.3 show vlt
This command is used to validate VLT configuration status on leaf switches in this topology. The Inter-chassis
link (ICL) Link Status, Heart Beat Status and VLT Peer Status must all be up. The role for one switch in the
VLT pair is primary and its peer switch (shown here) is assigned the secondary role. Ensure Peer-Routing is
shown as enabled.
S4148F-Leaf1#show vlt 127
Domain ID : 127
Unit ID : 2
Role : secondary
Version : 1.0
Local System MAC address : 14:18:77:25:49:b9
VLT MAC address : 14:18:77:25:56:b9
IP address : fda5:74c8:b79e:1::2
Delay-Restore timer : 90 seconds
Peer-Routing : Enabled
Peer-Routing-Timeout timer : 0 seconds
VLTi Link Status
port-channel1000 : up
